Mayku Mayku Multiplier Industrial Desktop Pressure Former
The Mayku Multiplier is an industrial pressure former for desktop use that delivers injection-molded level of detail and accuracy. It has a large 380mm (⌀) x 160mm (H) forming volume, pressure forms 0.5mm - 5mm thick sheets up to 60 psi, and heats materials up to 200ºC in less than two minutes. It includes automatic sheet leveling, 8 independent/redundant safety features, and WiFi updateable firmware.
- Forming Area of 380mm (⌀) x 160mm (H)
- Detail Resolution: Finer than a human hair
- Pressure forms 0.5mm - 5mm thick sheets
- Heat materials up to 220°C in 2 min.
- Upgrade with Reducing Plate to use more materials
- Activate Custom Mode to create your own material profile
| Price: | $10,499.00 (with add-ons) |
|---|---|
| Availability: | Allow up to 1 week for delivery |
| Order Now: | Processed Immediately Ships via Freight - some fees may apply. |
MAYKU MULTIPLIER
PRECISION PRESSURE FORMING FABRICATION
The Mayku Multiplier delivers industrial performance pressure forming so you can produce parts with sub-micron levels of detail and accuracy to meet industrial specifications.
Key Features of the Mayku Multiplier:
- Achieves <1µm resolution
- Large 380mm (⌀) x 160mm (H) forming volume
- Pressure forms 0.5mm - 5mm thick sheets up to 60 psi (4 Bar)
- Heat materials up to 200ºC in less than two minutes
- Wi-Fi updatable firmware for up-to-date features/materials
- Includes automatic sheet leveling (no plastic droop)
- Includes 8 independent/redundant safety features
- Desktop-friendly size
Utilizing tech that applies pressure more than 4x more powerful than a vacuum former, the Mayku Multiplier creates high-resolution parts that are nearly on par with injection molded parts.
- Compresses air up to 60 psi
- Generates five tonnes of force to create the highly detailed mold
- Create accurate parts at a fraction of industrial manufacturing costs
GO BIG OR PRINT BATCHES
The Multiplier is designed with a circular 380mm forming area and 160mm of height giving you the flexibility to either make large parts or multiple smaller ones in a single go.
- Forming Area: 380mm (⌀) x 160mm (H)
- Powerful pressure former keeps up with larger forming area
- Build size is perfect for prototyping and production applications
The Mayku Multiplier combines powerful pressure-forming technology and a wide forming area to decrease your manufacturing output down to minutes.
- Create molds and parts in under 5 minutes
- In-house manufacturing gives you full control over the output
- Save yourself weeks of lead time from outsourcing prototyping/production
SMART FEATURES FOR A SMART WORKFLOW
Mayku's Multiplier comes with tons of smart features for a seamless pressure-forming workflow.
- LCD Screen offers more power over precision and settings
- Wi-Fi connectivity for up-to-date features and materials
- Firmware tracks the progress of pressure-forming jobs
- Auto leveling system ensures sheets remain completely horizontal
ACTIVATE CUSTOM MODE TO CREATE MATERIAL PROFILES
Mayku's Multiplier allows you to use a variety of materials for your pressure-forming projects. If you are using a material that doesn't already have a predefined profile/settings, simply use the Custom Mode and create profiles for your specific materials.
- Use a wide variety of materials quickly and efficiently
- Save all your custom material profiles for repeat use
- Upgrade to the Reducing Plate to expand even more options in standard sheet sizes
See How Customers are Succeeding with the Mayku Multiplier
The Mayku Multiplier is being used everyday in a wide variety of industries - download some of the articles/case studies below to learn more:
HOW DOES IT WORK?
With Mayku Multiplier's user-friendly workflow, operation is simple for all skill levels right out of the box.
STEP 1 - CREATE TEMPLATE
Use a 3D printer, CNC milling machine, or another process to create a template to form over.
STEP 2 - SELECT MATERIAL
Choose a material profile from the machine's menu or use custom mode to create your own custom profile.
STEP 3 - INSERT TEMPLATE
Wait while the Multiplier heats your material precisely. The auto-leveling system will keep it level while bringing it to the forming temperature.
STEP 4 - FORM PART
Close the machine, and the Multiplier applies up to 4 atmospheres of pressure, exerting up to 5 tonnes of force on your material, pushing it into every detail of your template.
What are the Differences Between the Mayku Formbox and Multiplier?
 |  | |
|---|---|---|
| Model | Formbox | Multiplier |
| Price | $599 | $10,499 |
| Technology | Vacuum Former | Pressure Former |
| Forming Bed Dimensions | 200 × 200 x 130mm (7.87" x 7.87" x 5.12") | 380mm × 380 x 160mm (15.7" x 15.7" x 6.29") |
| Design Safe Space | 160 × 160mm (6.29" x 6.29") | 380 x 380mm (11.02" x 11.02") |
| Draw Depth | 130mm (5.12") | 160mm (6.29") |
| Min. Sheet Thickness | 0.25mm | 0.5mm |
| Detail Resolution | 0.01mm | Finer than a human hair |
| Max. Chamber Temp | 340°C | 220°C |
| LCD Display | ✔️ | |
| WiFi Connectivity | ✔️ | |
| Automatic Sheet Leveling | ✔️ | |
| Plastic Temperature Control | ✔️ | |
| Built-In Heated Pressure Chamber | ✔️ | |
| External Vacuum Required | ✔️ | |
| Easy Portability | ✔️ | |
| Desktop-Friendly | ✔️ | ✔️ |
| Fully-Assembled | ✔️ | ✔️ |
| Operating Voltage | 110V / 240V | 110V / 240V |
| Machine Dimensions (L x W x H) | 315 x 274 x 466mm (12.4 x 10.79 x 18.35 in) | 585 x 515 x 420mm (23.03" x 20.28" x 16.54") |
| Weight (Boxed) | 13kg (29 lbs) | 68kg (150 lbs) |
| Warranty Period | 1 Year (Limited) | 1 Year (Limited) |
| Ideal Applications | ✔️ EDU ✔️ Startups ✔️ Makerspaces | ✔️ EDU ✔️ Growing Businesses ✔️ Makerspaces Scaling Up ✔️ Design ✔️ Professional Kitchens |
| Compatible Mayku Forming Materials | Form sheet Resin sheet Clear sheet Flex sheet | PETG HIPS EVA |
| Compatible Casting Materials | Concrete Water Silicone Foam Chocolate Jesmonite Jello Plaster Resin | Concrete Water Silicone Foam Chocolate Jesmonite Jello Plaster Resin |
What Comes with the Mayku Multiplier?
 |
| Machine |
| 1 × Mayku Multiplier |
| 1 × A4 Reducing Plate |
| 1 × Application Support |
| 1 × Industrial Firmware |
| 1 × First Make Kit |
| 1 × Tool Kit |
| 1 × Power Cable |
| 1 × Instruction Manual |
| 1 × Activation Leaflet |
If purchasing with the Carbon Fibre Pressure Plate...
 |
| Carbon Fibre Mode (Pressure Plate) |
| 1 × Carbon Fibre Pressure Plate |
| 1 × Carbon Fibre Firmware |
| 1 × Sample Part (Carbon Fibre Bike Seat) |
An extended warranty for the Mayku Multiplier is available for purchase. Depending on your selection, you can extend the included standard 1-year warranty an additional year or three for a total of either 2 or 4 years of coverage.
What are the Technical Specifications of the Mayku Multiplier?
| GENERAL | |
|---|---|
| Technology | Desktop Pressure Former |
| Assembly | Fully-Assembled |
| Made in | China |
| MACHINE DIMENSIONS | |
| Outer Dimensions (L x W x H) | 585mm1 x 515mm x 420mm (23.03" x 20.28" x 16.54") |
| Weight | 57kg (125lbs) |
| PRESSURE FORMER PARAMETERS | |
| Forming Bed Dimensions (⌀ x H) | 380mm x 160mm (15" x 6.3") |
| Max. Template Volume | 3500cm3 / 214in3 |
| Design Safe Space | 380mm × 380mm (15" x 15") |
| Draw Depth | 160mm (6.3") |
| Max. Forming Pressure | Dome 4.1 bar/60 psi Tank 11 bar/160 psi |
| Min. Sheet Thickness | 0.5mm |
| Max. Sheet Thickness | 5mm (without Reducing Plate) >5mm (with Reducing Plate) |
| Detail Resolution | less than 1µm |
| ADDITIONAL FEATURES | |
| Custom Material Profiles | Unlimited; Compatible with any thermoplastic |
| Safety Features | ✓ (8 types available) |
| Updatable Firmware | ✓ (via WiFi) |
| Plastic Temperature Control | Precision IR Sensor |
| Self-Testing | Built-In (Maintenance for ease of use) |
| Air Outlet | Built-In (for tools and accessories) |
| CERTIFICATION(S) | |
| CE | ✓ |
| FCC | ✓ |
| UKCA | ✓ |
| RCM | ✓ |
| COMMUNICATION | |
| Display | High Contrast LCD Screen |
| Display Resolution | 720x720 |
| Connectivity | WiFi |
| POWER | |
| Input Voltage | 110-240V, 12A/6A (Single Phase) |
| Max. Power | 1500W |
| ADDITIONAL TECHNICAL DATA | |
| Max. Temperature in Chamber | 220°C / 392 °F |
| Operating/Storage Temperature | 5°C - 40°C (41°F - 104°F) |
| Sound Operation | up to 58-65 Decibels |
| Frequency | 2.4 GHz |
| PACKAGING | |
| Package Dimensions (L x W x H) | 700mm x 700mm x 640mm (27.56" x 27.56" x 25.2") |
| Package Weight | 68kg (150lbs) |
| WARRANTY | |
| Warranty Period | 1 Year OPTIONAL EXTENSION(S) 1 Additional Year 3 Additional Years |
1 This includes the length of the handles.
